This page provides a step-by-step example demonstrating the process of creating, configuring, and registering a [UI form component](https://docs.kentico.com/documentation/developers-and-admins/customization/extend-the-administration-interface/ui-form-components.md) in the system. The component renders a color selector and returns the selected color in the hexadecimal format. The example implementation also ensures that the component is displayed in a non-editable [state](https://docs.kentico.com/documentation/developers-and-admins/customization/extend-the-administration-interface/ui-form-components.md#editmode-on-the-front-end) when required by the admin UI.

For example, when used in [Page Builder widget properties](https://docs.kentico.com/documentation/developers-and-admins/development/builders/page-builder/widgets-for-page-builder/widget-properties.md), the component can enable users to set the color of some part or element rendered by the widget. See the following screenshot for an illustration.

![Color selector in widget properties](https://docs.kentico.com/docsassets/documentation/example-color-selector-ui-form-component/ColorSelectorUsage.png "Color selector in widget properties")

If you have not yet done so, prepare your development environment according to [Prepare your environment for admin development](https://docs.kentico.com/documentation/developers-and-admins/customization/extend-the-administration-interface/prepare-your-environment-for-admin-development.md). UI form components consist of both back-end and front-end code, so you'll need to prepare a custom JavaScript module as well.

> **Tip:** **Custom code best practices**
>
> We recommend separating admin UI customizations into a dedicated class library project. Using separate assemblies keeps the code intended for the admin UI separate from your site implementation. It also provides a convenient place to embed compiled JS modules with client code and simplifies certain [advanced deployment scenarios](https://docs.kentico.com/documentation/developers-and-admins/deployment/deploy-to-private-cloud/deploy-without-the-administration.md).

After your environment is set up, implement the component's back-end definition.

```csharp title="ColorSelectorFormComponent.cs"
using System.Threading.Tasks;

using Kentico.Xperience.Admin.Base.FormAnnotations;
using Kentico.Xperience.Admin.Base.Forms;

namespace Acme.Web.Admin.UIFormComponents.ColorSelector
{
    [ComponentAttribute(typeof(ColorSelectorComponentAttribute))]
    public class ColorSelectorFormComponent : FormComponent<ColorSelectorFormComponentClientProperties, string>
    {
        // The name of client React component to invoke, without the 'FormComponent' suffix
        public override string ClientComponentName => "@acme/web-admin/ColorSelector";

        protected override Task ConfigureClientProperties(ColorSelectorFormComponentClientProperties clientProperties)
        {
            base.ConfigureClientProperties(clientProperties);

            if (string.IsNullOrEmpty(clientProperties.Value))
            {
                // Initial state handling.
                // Sets the default value of the component (white) if no color was selected on the client.
                clientProperties.Value = "#FFFFFF";
            };

            return Task.CompletedTask;
        }
    }

    // Client properties class
    public class ColorSelectorFormComponentClientProperties : FormComponentClientProperties<string>
    {
    }
}
```

Next, define the [editing component attribute](https://docs.kentico.com/documentation/developers-and-admins/customization/extend-the-administration-interface/ui-form-components/editing-components.md) used for annotating other properties.

```csharp title="ColorSelectorComponentAttribute.cs"
using Kentico.Xperience.Admin.Base.FormAnnotations;

// The component doesn't define any custom configuration properties.
// The default attribute definition is therefore sufficient.
public class ColorSelectorComponentAttribute : FormComponentAttribute
{
}
```

Finally, write the React component that renders the user interface. The component makes use of a color picker from the [react-colorful](https://github.com/omgovich/react-colorful) library.

```json title="package.json"
"dependencies": {
    "react-colorful": "^5.x.x"
  },
```

```typescript title="Color selector component front-end (ColorSelectorFormComponent.tsx)"
import React, { useState } from 'react';

// Imports a color selector component from react-colorful
import { HexColorPicker } from "react-colorful";

import { FormComponentProps } from '@kentico/xperience-admin-base';
import { FormEditMode, FormItemWrapper } from '@kentico/xperience-admin-components';

export const ColorSelectorFormComponent = (props: FormComponentProps<string>) => {

    const handleOnChange = (value: string) => {
        // Passes the new user input to a parent component where all field
        // values are maintained. 'value' emitted by the color picker's onChange
        // event stores the most up to date input of the component.
        props.onChange?.(value);
    };

    // Renders the color selector in a state
    // corresponding to the 'editMode' value passed through 'props'.
    const renderColorSelector = () => {
        if (props.editMode === FormEditMode.ReadOnly) {
            return (
                <div>
                    The selected color is
                    <span style={{ color : props.value.toString() }}>{props.value}</span>.
                </div>
            );
        }

        else if (props.editMode === FormEditMode.Disabled) {
            return (
                renderDisabledSelector()
            );
        }

        else {
            // Renders the color selector in an editable state
            // and ensures the propagation of the selected value.
            return <HexColorPicker color={props.value} onChange={handleOnChange}/>;
        }
    };

    // Renders the color selector in a disabled state which prevents editing
    // and interaction with the component.
    const renderDisabledSelector = () => {
        return (
            <div style={{ position: "relative", display: "inline-block" }}>
                <HexColorPicker color={props.value}/>
                <div
                style={{
                    position: "absolute",
                    top: 0,
                    left: 0,
                    width: "100%",
                    height: "100%",
                    backgroundColor: "rgba(255,255,255,0.5)",
                    zIndex: 10,
                    }}
                />
            </div>
        );
    };

    // Renders the color selector and wraps it in 'FormItemWrapper' to ensure
    // the component works correctly inside forms.
    return (
        <FormItemWrapper
            label={props.label}
            explanationText={props.explanationText}
            invalid={props.invalid}
            validationMessage={props.validationMessage}
            markAsRequired={props.required}
            labelIcon={props.tooltip ? 'xp-i-circle' : undefined}
            labelIconTooltip={props.tooltip}
            editMode={props.editMode}
        >
            {renderColorSelector()}
        </FormItemWrapper>
    );
};
```

To make the component available from the admin UI, it must be exported from the client module's **entry.tsx**:

```tsx title="entry.tsx"
// Export the full path to the component file
export * from './form-components/ColorSelectorFormComponent';
```

The UI form component is ready for use in [builder component dialogs](https://docs.kentico.com/documentation/developers-and-admins/development/builders.md) and [model-driven UI forms](https://docs.kentico.com/documentation/developers-and-admins/customization/extend-the-administration-interface/ui-pages/ui-pages-with-forms.md). To enable usage in the [field editor](https://docs.kentico.com/documentation/developers-and-admins/customization/field-editor.md), register the component using `RegisterFormComponent`.

```csharp title="Form component registration"
using Kentico.Xperience.Admin.Base.Forms;

[assembly: RegisterFormComponent("Acme.UIFormComponents.ColorSelector",
                                 typeof(ColorSelectorFormComponent),
                                 "Color selector")]
```
